Rated at 5 tonne folds flat for convenient storage.

Ground Grabber is a strong and effective ground anchor for four wheel drive vehicle recovery.

It provides a winching point where no natural anchor point exists and is easy to use, as it requires minimum preparation.

Ground Grabber is constructed from high tensile steel with a folding share plate for easier transport.

Available in 5 tonne rating and a slightly shorter and lighter version rated at 3.5 tonne.

GROUND GRABBER®

Ground Grabber® is a strong and effective self-recovery ground anchor for four-wheel drive vehicle recovery. It provides a winching point where no natural anchor point exists and is easy to use, as it requires minimum preparation.

Ground Grabber® mast is constructed from high strength box section steel and share plate from 350 grade steel which has a rating of five tonnes or 3.5 tonnes depending on the model.

Preparation:

1. Rotate the ground-piercing blade 90 degrees from storage transport position to action position and lock the blade using the eye nut. The nut needs to be very tight, we suggest using a tyre lever.

2. Connect a rope to the eye nut for retrieval after vehicle recovery.

3. Attach the winch rope/cable to the steel loop at the end of the mast and holding the Ground Grabber® thrust and engage the ground piercing blade into the ground.

4. Engage the winch; the Ground Grabber® will dive into the ground. When firmly positioned engage low range 1st gear and winch.

Note:
In the event that ground penetration is not achieved repeating the process in the same location as previously used will assist Ground Grabber® as a deeper and more effective furrow will be created to gain a better footing.

When winching over a hill / dune Ground Grabber® should be positioned as far as possible beyond the crest to allow the vehicle to winch over the top of the rise without stopping.

Ground Grabber retrieval:

1. Disconnect winch rope/cable from Ground Grabber®
2. Drive vehicle straddling Ground Grabber®.
3. Attach retrieval rope to tow bar.
4. Drive forward slowly so the anchor is removed the opposite way to which it went in.

Note:
In soft sand attach a rope to the eye nut that is at least 4- 5 metres long as the diving action of the anchor may require a longer than usual rope to ensure easy retrieval once vehicle has been recovered.

Ground Self Recovery Anchor 3.5 & 5 tonne maximum working load models available
